Duraguard AFSC30Q 37w DuraLED Sculptor II Square Canopy
Description: The DuraGuard AFSC30Q Sculptor II Architectural Square Canopy is available in Type II, III, IV or V distributions designed to replace HID lighting systems up to 400w MH or HPS. Typical area lighting applications include retail centers, industrial parks, schools and universities, public transport and airports, office buildings and medical facilities. Mounting heights of 12 to 30 feet can be used based on light level and uniformity requirements.
Specifications and Features:
Housing: Die Cast and Sand Cast Aluminum Housing, Integral Heat Sinking. Includes 3' Cord.
Listing & Ratings: CSA: Listed for Wet Locations, ANSI/UL 1598, 8750; IP65 (IP66 with Pendant (PA) and Trunnion (T) Mounts Only)
Finish: Bronze or White Powdercoat Finish Over a Chromate Conversion Coating. Custom Colors Available Upon Request.
Lens: Clear UV-Stabilized Polycarbonate Vandal-Resistant Array Lens with Integral Optics or SoftLED LumaLens Opal UV-Stabilized Polycarbonate Vandal-Resistant Lens. Gasketed to Seal LED Array.
Mounting Options: Surface Mount Model (NM) Includes Easy-Hang Bracket Allowing One-Person Installation, Fits Standard 4" Electrical Box. Adjustable Height Trunnion (T) and Pendant (PA) Models are Shipped Ready For Field Installation of the Mount. Mounts are Shipped in a Separate Carton.
Wattage:
37w Array: 37w, System: 41w; (70-150w HID Equivalent)
65w Array: 65.3w, System: 72w; (150-250w HID Equivalent)
100w Array: 100w, System: 111w; (150-250w HID Equivalent)
140w Array: 139.9w, System: 156w; (250-400w HID Equivalent)
Driver: Electronic Driver, 120-277V, 50/60Hz or 347-480V, 50/60Hz; Less Than 20% THD and PF>0.90. Standard Internal Surge Protection 6kV. 0-10V Dimming Standard for a Dimming Range of 100% to 10%; Dimming Source Current is 150 Microamps.
| Part Number | AFSC30Q |
|---|---|
| Manufacturer | DuraGuard |
| Watts | 38 Watts, 65 Watts, 100 Watts, 140 Watts |
| Lumens | 5469-20,791 |
| Lumens Per Watt | 119-131 |
| CRI | 70 |
| Color Temperature | 3000 Kelvin, 4000 Kelvin, 5000 Kelvin |
| Rated Life | 345,000 hours + |
| Minimum Operating Temperature | -40 ° F |
| Maximum Operating Temperature | 122 ° F |
| Dimensions | 18" L x 18" W x 4" H |
| Certifications |  |
| Warranty | 5 Year |
| Lead Time | In Stock - Quick Ship |
