The DuraGuard DSLFQ flood light luminaire is available with a knuckle mounting configuration and medium flood distribution designed to replace HID lighting systems up to 100w MH or HPS. Typical lighting applications include retail centers, industrial parks, schools and universities, public transit and airports, office buildings and medical facilities. Mounting can be accomplished using ground attachment accessories and to heights of 16 feet based on light level and uniformity requirements.
Description: The DuraGuard DSLFQ flood light luminaire is available with a knuckle mounting configuration and medium flood distribution designed to replace HID lighting systems up to 100w MH or HPS. Typical lighting applications include retail centers, industrial parks, schools and universities, public transit and airports, office buildings and medical facilities. Mounting can be accomplished using ground attachment accessories and to heights of 16 feet based on light level and uniformity requirements.
Specifications and Features:
Housing: Die-Cast Aluminum Housing & Hinged Gasketed Lens Frame. Nickel-Plated Stainless Steel Hardware.
Listing & Ratings: CSA: Listed for Wet Locations, ANSI/UL 1598, 8750 IP65 Sealed LED Compartment.
Finish: Textured Architectural Bronze Powdercoat Finish Over a Chromate Conversion Coating. Custom Colors Available Upon Request.
Lens: Tempered Clear Flat Glass Lens
Mounting Options: Adjustable Knuckle with Angle Indicators & 1⁄2 ̋ NPS Threads.
Wattage: Array: 21.7w, System: 25w (100w HID Equivalent)
Driver: Electronic Driver, 120-277V, 50/60Hz or 347-480V, 50/60Hz; Less Than 20% THD and PF>0.90. Standard Internal Surge Protection 2kV. 0-10V Dimming Standard for a Dimming Range of 100% to 10%; Dimming Source Current is 150 Microamps.
Part Number | DSFLQ |
---|---|
Manufacturer | DuraGuard |
Watts | 25 Watts |
Lumens | 2123 |
CRI | 80 |
Color Temperature | 5000 Kelvin |
Rated Life | 345,000 hours + |
Minimum Operating Temperature | -40 ° F |
Maximum Operating Temperature | 122 ° F |
Dimensions | 7.5" L x 9" W x 7" H |
Certifications | |
Warranty | 5 Year |
Lead Time | In Stock - Quick Ship |
