Eiko PSC-WCM-450-BLE-SR BLE Wireless Control Module 120-277 Volt 16A Relay 12634
The NLC Wireless Control Module provides seamless Bluetooth mesh connectivity for networked lighting control systems. It allows easy setup and control via a free iOS app, without the need for hubs or routers.
HIGHLIGHTS
• Line Voltage input Control Module for Network Lighting Controls (NLC) using SIG Qualified Bluetooth mesh
• The free iOS App powered by Silvair is used for onsite commissioning, which includes setting up areas/grouping/zoning, creating profiles which include setting high and low end trim, as well as personal control
• The Web App powered by Silviar is used for optional offsite pre-planning, which includes setting up areas/grouping/zoning (pre-commissioning not required) and creating profiles (includes setting high and low end trim, and time delay)
• No hubs, gateway, or routers are required to make a complete mesh network. The unit can pair with the Silvair iOS App to allow initial setup and subsequent adjustments
• Easily incorporate additional BLE devices like wall/wireless controllers, sensors, fixture controllers, range extenders, and timekeepers
• Over-the-air Firmware upgrade available via iOS App
• A device that is part of EiKO's NLC System
CERTIFICATIONS
• cULus Listed for Damp Locations
• IP20 Rated
• FCC Compliant
• RoHS Compliant
PERFORMANCE
• Onboard Omnidirectional Antenna
• Operational frequency: 2.4 GHz - 2.483 GHz
• Communication range: max. 100ft*
• Continuous 0-10V Bi-Level Dimming
ELECTRICAL
• Input voltage: 120-277VAC
• Load (20A Relay): @120/277VAC Max. 16A E. Ballast, LED, CFL
• 0-10V: 100mA Sink Current
• Auxiliary Power Supply: 12VDC 300mA for Sensor
THERMAL
• -40°F to 104°F (-40°C to 40°C) Operating temperature
CONSTRUCTION
• White plastic housing
• 1/2" knockout with locknut installation
WARRANTY
• 5-Year limited warranty available online. Please get in touch with your EiKO sales representative for additional details.
APPLICATIONS
• Warehouses
• Manufacturing Plants
• Distribution Centers
• 24-hour Fitness Centers
• Offices
*Communication range highly depends on the integrated fixtures, the surrounding environment, and conditions.
It is recommended to conduct testing in each unique application for range accuracy.
For a longer communication range, a Range Extender is recommended (per zone).
| Part Number | PSC-WCM-450-BLE-SR |
|---|---|
| Manufacturer | Eiko |
| Warranty | 5 Year |
| Load Capacity | 16 A |
| Certifications |    |
| Length | 4 |
| Width | 2 |
| Height | 1 |
| UPC Code | 031293126344 |
| Lead Time | In Stock - Quick Ship |
