Halco PSC-JBV-I-11N-BLE-SR TruBlu Mesh Wireless PIR Panel & Troffer Sensor Controller 12-24 VDC 0-10V White Finish 25421

Designed for a wide range of indoor applications, they operate in ambient temperatures from –20 to 70 °C. The devices are Bluetooth NLC certified and are wirelessly controlled via Bluetooth Mesh technology, enabling wireless dimming of luminaires. Their compact design allows for seamless integration into the fixture.

• Bluetooth PIR Sensor/Controller for use with Panels & Troffers with 3.5mm audio jack base
• Fits seamlessly into Halco's Control Ready Flat Panels & Troffers
• Bluetooth range up to 100Ft
• 0-10V Dimming, 1-Channel, Integrated Photosensor, Zoning
• Mounting Height to 15FT Sensor Detection Range 6FT Diameter
• Configurable using the mwConnect TruBlu web Portal or iOS Phone App

Wireless PIR Occupancy Sensor – with Audio Jack
• Bluetooth® NLC Certified
• 1-Channel 0-10VDC Dimming
• PIR Sensor Mounting Height Up To 15ft (4.6m)
• Daylight Harvesting, High-End Trim, Zoning, Continuous Dimming, ON/OFF control
• Indoor rated
• 3.5mm Audio Jack

Key Features
• 1-channel PIR sensor and controller
• 12VDC input, 30 mA current consumption
• Mounting height up to 15 ft (4.6 m)
• Detection range up to 6 ft (1.8 m) radius
• Bluetooth range up to 100 ft (30.4 m)
• Operating temperature –20°C to 40°C
• Storage temperature –20°C to 50°C
• 90–95% non-condensing relative humidity

Operation
• Bluetooth® NLC certified device providing true multi-vendor interoperability
• Configurable via TruBlu™ web portal or iOS mobile app
• Mobile app used for initial commissioning and ongoing parameter adjustments
• Energy monitoring and demand response available with TruBlu™ Gateway (ordered separately)
• Provides one 0–10V dimming channel for driver control
• Integrated photo sensor for ambient light sensing
• 3.5mm Audio Jack Mounting
