The Mirada Post Top (MPP) transcends traditional lighting by blending modern aesthetics and urban architectural style seamlessly. Its day-form can bring an organic look into environments and it’s after dusk features include premium distributions, high product configurability, and intelligent controls. The Mirada Post Top (MPP) creates a paradox of unrecognized aesthetics and performance to enhance any site.

- 9 Industry-leading distributions utilizing LSI’s Exclusive Molded Silicone Optical System
- 5 Standard lumen packages
- Three piece rigid Die-cast Aluminum Housing with cast-in stainless cage wire-way to provide IP66 Rating on the entire luminaire for maximum ingress protection
- Intelligent wireless control options available to achieve code compliance, energy savings, and more
- US & Int'l. patents pending
- 5-year Warranty

Optical System
• State-of-the-Art one piece silicone optic sheet delivers industry leading optical control with an integrated gasket to provide IP66 rated sealed optical chamber in 1 component.
• Proprietary silicone refractor optics provide exceptional coverage and uniformity in IES Types 2, 3, 5W, FT and FTA.
• Silicone optical material does not yellow or crack with age and provides a typical light transmittance of 93%.
• Available in 5000K, 4000K, 3000K, and 2700K color temperatures per ANSI C78.377.
• Minimum CRI of 70. Optional 80 CRI available, consult factory for lead time.
• Integral Louver (IL) option available for improved back-light control without sacrificing street side performance. See page 5 for more details.
• Minimal uplight with less than 3% of the total lumen output going above 90D.
Electrical
• High-performance driver features over-voltage, under-voltage, short-circuit and over temperature protection.
• 0-10V dimming (10% - 100%) standard.
• Standard Universal Voltage (120-277 Vac) Input 50/60 Hz or optional High Voltage (347-480 Vac).
• L92 Calculated Life: >100k Hours (See Lumen Maintenance on Page 2)
• Total harmonic distortion: <20%
• Operating temperature: -40°C to +50°C (-40°F to +122°F). 72L Package is limited to 40ºC.
• Power factor: >.90
• Input power stays constant over life. • Field replaceable surge protection device meets a minimum Category C Low operation (per ANSI/IEEE C62.41.2).
• High-efficacy LEDs mounted to metal-core circuit board to maximize heat dissipation
• Components are fully encased in potting material for moisture resistance. Driver complies with FCC standards.
• Internal power supplies and controls can be serviced via (2) integral fitter removable power trays.
Construction
• Rugged die-cast aluminum optical housing, cage, and fitter. Fitter contains factory pre-wired drivers and optional controls.
• Complete die-cast aluminum construction for maximum quality and surface finish.
• 1-PC die-cast aluminum cage with wire passages allows for IP66 full luminaire rating to protect integral components from harsh environments.
• Luminaire is proudly manufactured in the U.S. of U.S. and imported parts.
• 3G rated for ANSI C136.31 high vibration applications
• Fixtures are finished with LSI’s DuraGrip® polyester powder coat finishing process. The DuraGrip finish withstands extreme weather changes without cracking or peeling. Other standard LSI finishes available. Consult factory.
• Shipping weight: 55 lbs in carton.
Controls
Wireless Controls System
To make this fixture AirLink ready, simply order the integrated Wireless Lighting Controller: ALSC or ALSCH (see ordering guide) as the controls option. To see how the components of AirLink system work together, reference the diagram in the controls section of this spec sheet.
Stand-Alone Controls.
• The 7-pin ANSI C136.41-2013 photocontrol receptacle option (CR7P) is available for twist lock photocontrols.
Installation
• Designed to mount to 2-3/8”-3” OD x 3” to 4-1/2” tall tenon.
• Secures to tennon with 8 stainless steel set screws.
• 6’ wire leads with strain relief zip-ties are provided in fitter for ease of wiring.
Warranty
• LSI LED Fixtures carry a 5-year warranty
Listings
• Listed to UL 1598 and UL 8750.
• RoHS Compliant.
• American Recovery and Reinvestment Act Funding Compliant.
• Suitable For wet Locations.
• IP66 rated Luminaire per IEC 60598. IP66 rated optical chamber.
• 3G rated for ANSI C136.31 high vibration applications
• DesignLights Consortium® (DLC) qualified product. Not all versions of this product may be DLC qualified. Please check the DLC Qualified Products List at www.designlights.org/QPL to confirm which versions are qualified.
